The diagnostic characters of Mastogloia similis Hustedt and of Mastogoia paradoxa
Grunow are nearly identical. As indicated by Hustedt (1931-1959,
p. 522), only the shape of the raphe distinguishes the 2 species. The raphe of Mastogloia similis is straight while that of Mastogloiaparadoxa is sinuous.
In the samples from the French Lesser Antilles, most of the observed valves of "Mastogloia similis/paradoxa" had a straight raphe, as on the valve illustrated below, and so they have been considered as belonging to the species Mastogloia similis.
Mastogloia similis , Longueur: 36 µm. Marie-Galante.
In the plate 23a in Loir & Novarino (see below), the valves A, C and D1 have a straight raphe while the valve D2 has a sinuous raphe. Yet the valves D1 and D2 are from the same frustule.
A different shape of the raphes of the 2 valves of a frustule was in
some cases observed (when we were lucky to find not dismantled
frustules)
Two cases are illustrated below :
